Our products conform to GB, AISI, ASTM, DIN, EN, JIS standard for stainlesss steel coil, sheet and plate.
Product Name |
Stainless Steel Plate, Stainless Stainless Sheet, Nickel Alloy Plate, Nickel Alloy Sheet |
Standard |
GB, AISI, ASTM,DIN, EN, JIS |
Available Grades |
300 Series: 304, 304L, 304H, 309, 309S, 310, 310S, 316, 316L, 317, 317L, 321, 321H, 347, 347H |
400 Series: 409, 410S, 416, 420, 430, 439, 440, 444, 446 |
|
Duplex and Others: 2205, 2507, S31803, S32205, S32750, S32760, 253MA, 254SMO, 904L etc |
|
Process |
Hot Rolled, Cold Rolled, Forged |
Sizes |
Thickness: 0.3-200mm, Width: 10-4000mm |
Surface Treatment |
NO.1, 1D, 2D, 2B, NO.4, BA, HL, Mirror, Embossim, Sandblasted |
Fabricating |
Rolling, Bending, Sllitting, Decoiling, Cutting, Drilling, Punching, Beveling, Welding etc. |
Application |
Oil&Gas, Petroleum, Vessels, Ship Building, Water Treatment And Environmental Protection etc. |
304/304L/304H STAINLESS STEEL PLATE
316/316L STAINLESS STEEL PLATE
321/321H STAINLESS STEEL PLATE
310/310S STAINLESS STEEL PLATE
309/309S STAINLESS STEEL PLATE
2205/2507 STAINLESS STEEL PLATE
904L STAINLESS STEEL PLATE
410/410S STAINLESS STEEL PLATE
420/430 STAINLESS STEEL PLATE
304 Stainless Steel Chequered Plates
Chemical.Component | C | Mn | P | S | Si | Cr | Ni | Mo | N | Cu | |||||
304 | 0.07 | 2.00 | 0.045 | 0.03 | 0.75 | 17.50-19.50 | 8.00-10.5 | / | 0.10 | / | |||||
304L | 0.03 | 2.00 | 0.045 | 0.03 | 0.75 | 17.50-19.50 | 8.00-12.00 | / | 0.10 | / | |||||
304H | 0.10 | 2.00 | 0.045 | 0.03 | 0.75 | 17.50-19.50 | 8.00-10.5 | / | 0.10 | / | |||||
309 | 0.20 | 2.00 | 0.045 | 0.03 | 0.75 | 22.00-24.00 | 12.00-15.00 | / | / | / | |||||
309S | 0.08 | 2.00 | 0.045 | 0.03 | 0.75 | 22.00-24.00 | 12.00-15.00 | / | / | / | |||||
310 | 0.25 | 2.00 | 0.045 | 0.03 | 1.50 | 24.00-26.00 | 19.00-22.00 | / | / | / | |||||
310S | 0.08 | 2.00 | 0.045 | 0.03 | 1.50 | 24.00-26.00 | 19.00-22.00 | / | / | / | |||||
316 | 0.08 | 2.00 | 0.045 | 0.03 | 0.75 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 | 0.10 | / | |||||
316L | 0.03 | 2.00 | 0.045 | 0.03 | 0.75 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 | 0.10 | / | |||||
317 | 0.08 | 2.00 | 0.045 | 0.03 | 0.75 | 18.00-20.00 | 11.00-15.00 | 3.00-4.00 | 0.10 | / | |||||
317L | 0.035 | 2.00 | 0.045 | 0.03 | 0.75 | 18.00-20.00 | 11.00-15.00 | 3.00-4.00 | / | / | |||||
321 | 0.08 | 2.00 | 0.045 | 0.03 | 0.75 | 17.00-19.00 | 9.00-12.00 | / | 0.10 | / | |||||
347 | 0.08 | 2.00 | 0.045 | 0.03 | 0.75 | 17.00-19.00 | 9.00-13.00 | / | / | / | |||||
409 | 0.03 | 1.00 | 0.04 | 0.02 | 1.00 | 10.50-11.70 | 11.70 | 0.50 | / | 0.03 | |||||
410S | 0.08 | 1.00 | 0.04 | 0.03 | 1.00 | 11.50-13.50 | 0.60 | / | / | / | |||||
420 | 0.15 | 1.00 | 0.04 | 0.03 | 1.00 | 12.00-14.00 | 0.75 | 0.50 | / | / | |||||
430 | 0.12 | 1.00 | 0.04 | 0.03 | 1.00 | 16.00-18.00 | 0.75 | / | / | / | |||||
439 | 0.03 | 1.00 | 0.04 | 0.03 | 1.00 | 17.00-19.00 | 0.50 | / | 0.03 | / | |||||
2205 | 0.03 | 2.00 | 0.03 | 0.02 | 1.00 | 22.00-23.00 | 4.50-6.50 | 3.00-5.00 | 0.14-0.20 | / | |||||
2507 | 0.03 | 1.20 | 0.035 | 0.02 | 0.80 | 24.00-26.00 | 6.00-8.00 | 3.00-5.00 | 0.24-0.32 | 0.50 | |||||
31803 | 0.03 | 2.00 | 0.03 | 0.02 | 1.00 | 21.00-23.00 | 4.50-6.50 | 2.50-3.50 | 0.08-0.20 | / | |||||
253MA | 0.08 | 0.80 | 0.04 | 0.03 | 1.60 | 21.00 | 11.00 | / | 0.17 | / | |||||
254SMO | 0.02 | 1.00 | 0.03 | 0.01 | 0.80 | 19.50-20.50 | 17.05-18.50 | 6.00-6.50 | 0.18-0.22 | 0.50-1.00 | |||||
904L | 0.02 | 2.00 | 0.045 | 0.035 | 1.00 | 19.00-23.00 | 23.00-28.00 | 4.00-5.00 | 0.10 | 1.00-2.00 |
Mechanical Property | Tensile Strength, min | Yield Strength, min | Elongation | Hardness, max | |||||||||||
ksi | Mpa | ksi | Mpa | / | Brinell.HBW | Rockwell | |||||||||
304 | 75 | 515 | 30 | 205 | 40 | 201 | 92HRBW | ||||||||
304L | 70 | 485 | 25 | 170 | 40 | 201 | 92HRBW | ||||||||
304H | 75 | 515 | 30 | 205 | 40 | 201 | 92HRBW | ||||||||
309 | 75 | 515 | 30 | 205 | 40 | 217 | 95HRBW | ||||||||
309S | 75 | 515 | 30 | 205 | 40 | 217 | 95HRBW | ||||||||
310 | 75 | 515 | 30 | 205 | 40 | 217 | 95HRBW | ||||||||
310S | 75 | 515 | 30 | 205 | 40 | 217 | 95HRBW | ||||||||
316 | 75 | 515 | 30 | 205 | 40 | 217 | 95HRBW | ||||||||
316L | 70 | 485 | 25 | 170 | 40 | 217 | 95HRBW | ||||||||
317 | 75 | 515 | 30 | 205 | 35 | 217 | 95HRBW | ||||||||
317L | 75 | 515 | 30 | 205 | 40 | 217 | 95HRBW | ||||||||
321 | 75 | 515 | 30 | 205 | 40 | 217 | 95HRBW | ||||||||
347 | 75 | 515 | 30 | 205 | 40 | 201 | 92HRBW | ||||||||
409 | 55 | 380 | 25 | 170 | 20 | 179 | 88HRBW | ||||||||
410S | 60 | 415 | 30 | 205 | 22 | 183 | 89HRBW | ||||||||
420 | 100 | 690 | / | / | 15 | 217 | 96HRBW | ||||||||
430 | 65 | 450 | 30 | 205 | 22 | 183 | 89HRBW | ||||||||
439 | 60 | 415 | 30 | 205 | 22 | 183 | 89HRBW | ||||||||
2205 | 95 | 655 | 65 | 450 | 25 | 293 | 31HRC | ||||||||
2507 | 116 | 795 | 80 | 550 | 15 | 310 | 32HRC | ||||||||
31803 | 90 | 620 | 65 | 450 | 25 | 293 | 31HRC | ||||||||
253MA | 600 | 310 | 310 | 40 | 217 | 95HRBW | |||||||||
254SMO | 100 | 690 | 45 | 310 | 35 | 233 | 96HRBW | ||||||||
904L | 71 | 490 | 31 | 220 | 35 | / | 90HRBW |
Answer:
Stainless steel plate is one of the stainless steel product, available in various grades that offer a wide range of mechanical properties depending on the chemical composition, microstructure, and processing. Ronsco will deliver stainless steel plate to each customer’s exact specifications, including in the annealed hot rolled and pickled condition.
Single Sheet Of Rolling Specification | |||||||
Thickness/Width | 1500 | 1800 | 2000 | 2200 | 2400 | 2500 | 3200 |
4-6mm | √ | √ | - | - | - | - | - |
6-10mm | √ | √ | √ | √ | √ | - | - |
11-12mm | √ | √ | √ | √ | √ | √ | √ |
13-14mm | √ | √ | √ | √ | √ | √ | √ |
17-25mm | √ | √ | √ | √ | √ | √ | √ |
26-70mm | √ | √ | √ | √ | √ | √ | √ |
71-120mm | special | special | special | special | special | special | special |
Which Industries Will You See Stainless Steel Plate?
Answer:
Stainless steel plate can be seen across a range of industries including the oil&gas, petroleum, and vessels etc..
